詳細情報 |
|||
| モデル番号: | vs-052〜vs-400 | チャネルタイプ: | まっすぐ |
|---|---|---|---|
| 構造タイプ: | 浮遊球 | 操作方法: | レバー、ギア、空気圧、電気 |
| 体材: | 炭素鋼、ステンレス鋼、デュプレックスステンレス | サイズ範囲: | NPS 1/2 "-8"、DN15-200 |
| 圧力クラス: | クラス150-1500ポンド、PN 10-250 | 接続を終了します: | Flange、BW、SW、NPT |
| ボール素材: | フリーカッティングスチール、ステンレス鋼（1.4571/316ti） | シーリング材料: | プラスチック、金属 |
| 最大圧力: | PN500 | 温度範囲: | -20°C〜 +80°C（-4〜 +176°F） |
| 表面仕上げ: | 黒酸化物、亜鉛層、亜鉛ニッケル | 生産能力: | 50000pc/y |
| DN範囲: | DN04からDN25へ | ||
| ハイライト: | Class 150-1500 Lb Pneumatic Ball Valve,PN 10 ~ 250 Pneumatic Ball Valve,DN15-200 Pneumatic Ball Valve |
||
製品の説明
BKH - Block-Type Ball Valve with Pneumatic Actuator
High-performance 2-way ball valves designed for demanding industrial applications including construction machinery, agricultural equipment, mobile hydraulics, mining, and gas industries.
Key Features
- Available in sizes DN 4 to DN 25
- Multiple connection options including thread, compression fitting, and welding ends
- Robust construction with pressure ratings up to PN500
- Optional configurations with actuators, position switches, and locking devices
- Wide temperature range: -20°C to +80°C (-4 to +176°F)
Technical Specifications
| Component | Material |
|---|---|
| Body | S460N, S355 steel |
| Ball & Stem | Free cutting steel or stainless steel (1.4571/316Ti) |
| Sealing | Plastics or metal |
| Surface Treatment | Black oxide finishing, zinc-layer, or zinc nickel |
Connection Options
Compression fitting (light and heavy series), BSP thread, NPT thread, welding end and welding taper, UNC/UNF female thread, bulkhead connection, plug-in socket, plug nipple, and thread connection.
Applications
Ideal for hydraulic systems in construction, agriculture, mining, and gas industries. Materials and seals can be customized for specific application requirements.
